Automatic model diagram

Draws a compartment diagram of a model from its differential equations (see modelGraph() for how the equations are interpreted).

Usage

modelDiagram(
  object,
  dosing = NULL,
  data = NULL,
  engine = getOption("nlmixr2plot.diagram.engine"),
  labels = FALSE,
  ...
)

# S3 method for class 'nlmixr2ModelGraph'
plot(x, ..., engine = getOption("nlmixr2plot.diagram.engine"), labels = FALSE)

# S3 method for class 'rxUi'
plot(
  x,
  ...,
  dosing = NULL,
  data = NULL,
  engine = getOption("nlmixr2plot.diagram.engine"),
  labels = FALSE
)

# S3 method for class 'rxode2'
plot(
  x,
  ...,
  dosing = NULL,
  data = NULL,
  engine = getOption("nlmixr2plot.diagram.engine"),
  labels = FALSE
)

Arguments

object: model to diagram (see modelGraph()) or a nlmixr2ModelGraph object.
dosing: optional character vector naming the dosing compartments. When NULL the dosing compartments are detected from the dosing records in data (a dataset without dose records has no dosing compartment); when there is no data, or it has no evid/amt columns, the first compartment (the default rxode2 dosing compartment) is used.
data: optional dataset used to detect the dosing compartments (from the dosing records' cmt). For fitted models this defaults to the data the model was fit with.
engine: drawing engine: "DiagrammeR" (a Graphviz htmlwidget from the 'DiagrammeR' package), "ggplot2" (a ggplot object) or "dot" (the Graphviz DOT source as a character string, to customize or render elsewhere). The default is "DiagrammeR" when that package is installed and "ggplot2" otherwise; it may be changed with options(nlmixr2plot.diagram.engine = ...).
labels: logical; when TRUE label the arrows with the model terms.
...: ignored.
x: a nlmixr2ModelGraph object, an rxode2 user interface (rxUi) object or a compiled rxode2 model

Value

the diagram drawn by the requested engine.

Details

The layout follows common pharmacometric conventions: dosing and absorption/transit compartments are above the compartment they feed; the central compartment is in the middle with the compartments it exchanges mass with (peripheral compartments) to its left; unidirectional transfer (e.g. to a metabolite) and eliminations go below; compartments that interact with the model without mass transfer (e.g. effect compartments or pharmacodynamic models) go to the right, with their own inputs above, outputs below and exchange compartments further right.

Mass transfer is drawn with solid arrows; interactions without mass transfer are dashed (with a "tee" arrow head for inhibition and a "dot" arrow head when the direction is undetermined with DiagrammeR; dotted for inhibition and dot-dashed when undetermined with ggplot2).

plot() of an rxode2 user interface (rxUi) object, like rxode2::rxode2(modelFunction), or of a compiled rxode2 model draws its model diagram, so plot(rxode2(model)) is the same as modelDiagram(model). (A fitted nlmixr2 model keeps its goodness-of-fit plot(); use modelDiagram(fit) for its diagram.)

Author

Matthew L. Fidler

Examples

# \donttest{
pk.turnover.emax <- function() {
  ini({
    tktr <- log(1)
    tka <- log(1)
    tcl <- log(0.1)
    tv <- log(10)
    poplogit <- 2
    tec50 <- log(0.5)
    tkout <- log(0.05)
    te0 <- log(100)
    prop.err <- 0.1
    pkadd.err <- 0.1
    pdadd.err <- 10
  })
  model({
    ktr <- exp(tktr)
    ka <- exp(tka)
    cl <- exp(tcl)
    v <- exp(tv)
    emax <- expit(poplogit)
    ec50 <- exp(tec50)
    kout <- exp(tkout)
    e0 <- exp(te0)
    DCP <- center / v
    PD <- 1 - emax * DCP / (ec50 + DCP)
    effect(0) <- e0
    kin <- e0 * kout
    d/dt(depot) <- -ktr * depot
    d/dt(gut) <- ktr * depot - ka * gut
    d/dt(center) <- ka * gut - cl / v * center
    d/dt(effect) <- kin * PD - kout * effect
    cp <- center / v
    cp ~ prop(prop.err) + add(pkadd.err)
    effect ~ add(pdadd.err)
  })
}
modelDiagram(pk.turnover.emax, engine = "ggplot2")
#>
#>
#> ℹ parameter labels from comments are typically ignored in non-interactive mode
#> ℹ Need to run with the source intact to parse comments

if (requireNamespace("DiagrammeR", quietly = TRUE)) {
  modelDiagram(pk.turnover.emax, engine = "DiagrammeR")
}
#>
#>
#> ℹ parameter labels from comments are typically ignored in non-interactive mode
#> ℹ Need to run with the source intact to parse comments

# }
